    22KW 32A IP55 Commercial Electric Vehicle Charging Stations

    Ask Lasest Price
    Brand Name : ARK or OEM
    Model Number : AKEV22
    Certification : CE
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 1000 units per month
    Delivery Time : 25-45days
    • Product Details
    • Company Profile

    22KW 32A IP55 Commercial Electric Vehicle Charging Stations

    Ark Level 2 Commercial EV Charger Station with 22kW 32A AC Output and Wall Mount Installation

    Product Introduction

    Designed to be installed in both public access environments (urban spaces, shopping centres, car parks, airports, petrol stations…) and private areas (companies, community car park sites…) where its intelligent capabilities offer a range of possibilities which improve the user and/or operator experience.
    Product Parameters

    Technical specificationsAKEV22
    Housing materialMetal enclosure
    Dimension300*450*160mm, 1200*450*160mm (pedestal mount)
    Installation methodWall mount, pedestal mount (optional)
    Cable routingBottom inlet wiring
    WeightN.W.: 11kg
    Charging standardIEC 61851-22
    Charging outletType-2 socket or connector
    Outlet number1
    Input voltage230Vac +/-10% 1-phase400Vac +/-10%, 3-phase
    Input frequency50Hz/60Hz
    Output
    Max output power7kW22kW
    Measuring accuracyLevel 0.5
    Output voltage range230Vac +/-10% 1-phase400Vac +/-10%, 3-phase
    Output current range32A
    RCCBType-B, sensitivity: 30mA
    General
    Charging typeMode 3
    User InterfaceRFID, LCD Display
    AC connector typeIEC 62196 Type-2
    CommunicationPWM, Ethernet, LTE, OCPP 1.6J
    Application placeIndoor/Outdoor
    Working temperature-30 °C – +50 °C
    Working humidity5% – 95% non-condensation
    Altitude<2000m
    Protection gradeIP55
    CoolingNatural cooling
    Safety standardCompliant with CE, EN 61851-1-2001; EN 61851-21-2001; EN 61851-22-2001
    SecurityOver/under voltage protection, overload protection, current leakage protection, grounding protection, lightening surge protection

    22KW 32A IP55 Commercial Electric Vehicle Charging Stations22KW 32A IP55 Commercial Electric Vehicle Charging Stations

    Features
    The 4.3-inch display and unique user interface provide customers with a good experience.
    The LED status display allows customers to clearly understand the current status of the charger.
    Integrated with OCPP1.6,which make sure the charger can be connected to the background easily, reducing the workload for customers to manage the chargers.
    Application
    Shopping mall
    Company charging
    Parking lot
    Supermarket
    Company Introduction
    The foresight of the Ark Technology team can provide you with stable and reliable DC charging solutions and services. With rich experience and knowledge in electrical and digital power supply, we provide you with the most professional and practical project implementation guide. Our products have passed various application scenarios and laboratory standard tests. You can purchase our charging station products without any worries and get our professional service support.

    FAQ

    1. Why choose us as your preferred EV Charger supplier?

    I. The professional technical team and long-term vision of the industry ensure that we are always in the industry leading position. We offer a wide range of product options: charging stations for various charging standards, international standardization design, and smart back-end services.

    II. Our products have passed various application scenarios and laboratory standard tests. You can buy our charging station products without any concerns and receive our professional service support.

    III. The only Chinese EV Charger vendor who is willing and able to achieve CE and UL certificate currently.

    IV. Our team members are the first batch of sales and engineers who is working in developing and selling global standard EV DC Charger which ensure we have plenty of experience implement global EV DC charger projects and have the foresight to lead EV charger products.


    2. Is there any experience in implementing overseas charging station projects?

    Yes, actually we are the pioneers in implementing overseas charger projects. Till now, we cooperate with UK power company to integrate EV charger with PV system, with US charging operator to install dozens of EV DC charger along the Freeway from LA to San Francisco, with GM automaker to provide DC fast charging service to their Bolt EV fleet and several charging projects.


    3. What are the advantages of your products?

    I. Telecom level product design and production.

    II. Multiple charging standards support including CCS-1/2, CHAdeMO and GB/T, which means we can offer you all standards EV DC charger you want.

    III. Quality comes first with wider input & output voltage range, lower voltage output range, better temperature adapted, higher protection grade, a longer technical foresight and most advanced modular design.

    IV. Fast customer response, prefessional technical support and more solutions come out.


    4. Does the higher the charging station output power mean the faster the charging speed?

    No, it doesn't. Due to the limited power of the car battery at this stage, when the output power of the DC charger reaches a certain upper limit, the larger power does not bring a faster charging speed.

    However, the significance of high-power DC charger is that it can support dual connectors and simultaneously output high power to charge two electric vehicles at the same time, and in the future, when the electric vehicle battery is improved to support higher power charging, it is not necessary to invest money again to upgrade the charging station.


    5. If we purchase your EV DC charger, how to get your after-sales support?

    Under normal circumstances, we will provide comprehensive after-sales technical training, including providing written training materials, training videos or inviting customers' technical personnel to face-to-face training to help customers master parts replacement and basic maintenance work. When encountering an urgent situation, we will also send professional technicians to provide on-site support.
