Ark AREG50040 EV DC Charging Module Power Supply AC/DC Converter
with 15KW Output, CAN Communication and CCS CHAdeMO Compliant is
specially developed for the electrical vehicle DC fast charging. It
has high efficiency, power factor, high energy density, and good
reliability advantages. 3 phase without neutral AC input, DC output
voltage range from 150 to 550VDC, 15kW output power, compliant with
CE safety requirements, EMC standard EN55022 CLASS A, it is an
advanced international level charging rectifier and converter.
Unique Functions:
(1) Wider output voltage range: 150-550VDC, suitable for all EVs
(2) More power output in low voltage, 25% bigger than others
(3) A patent intelligent discharge circuit inside, improve the
system reliability and simplify the system design
(4) High temperature adapted: full power output at 55 ℃
(5) High efficiency in all level load, full load efficiency above
95.5%
(6) Low standby power consumption, less than 10W
Main Features:
(1) 3-phase without neutral input, eliminate the large neutral
current risk
(2) 3-phase active power factor correction technology, reduce the
harmonic interface to the grid
(3) Dual DSP design, achieve the full digital control, fewer
components means higher reliability
(4) Widest input voltage range in the industry: 260-530VAC,
operates in most grid, even the poor ones
(5) Wider range of operation temperature: -40 ℃-+75 ℃
(6) Considering salt fog resistance, moisture and mildew resistant
design, achieve strong environmental adaptability
(7) Hot plug-in design, easy to install
