Fast OCPP 1.6J Three Phase 132 Amp Wall Box EV Charger

Ask Lasest Price
Brand Name :	ARK
Model Number :	EF040CJ
Certification :	CE
Price :	8500USD/unit
Payment Terms :	T/T
Supply Ability :	500 units per month
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

Fast OCPP 1.6J Three Phase 132 Amp Wall Box EV Charger

Overview

Quick Details

Place of Origin:: Jiangsu, China

Model Number:: UF40K500C-W

Brand Name:: ARK or OEM

Input Voltage Range:: 400Vac +/-10%, 3-phase

Input Frequency Range:: 50Hz/60Hz

Output Voltage Range:: 150 - 750V DC, constant output @ above 300V

Output Current Range:: 0 - 132A

Rated Output Power:: CCS: 20kW, CHAdeMO: 20kW / CCS: 40kW, CHAdeMO: 40kW

Warranty:: 12 Months

Working Humidity:: 5%-95%

Working Temperature:: -20° C to +70° C

Charging Standards:: CCS & CHAdeMO

Efficiency:: >94%

Supply Ability

500 Unit/Units per Month

Packaging & Delivery

Wooden case package
850 x 650 x 1700 mm
Power modules outside the charger cabinet to be shipped to avoid the damage during shipping.
32 units per 40' Container

Product Introduction

ARK 30KW OCPP 1.6J Wallbox DC Fast EV charger with CCS & CHAdeMO two connectors for electronic cars

ARK 380V 400V 480V OUTPUT 0-550V 30kW CHAdeMO wall mounted EV DC
Fast charger for i3 Fast Charging is the most advanced Electric Vehicle Charging Station currently
available. Its modular design construction allows for free
configuration of power modules and electrical components,
application of a Ethernet/WiFi/3g/4g communication or RFID card
reader.

This series chargers can be operated stably in various application
scenarios and envrionments, even if low or high temperatures.

Product Parameters

Specification	Model	EF040CJ
Structure	Application scenes	Parking lot/Public charging station
	Housing material	Metal case
	Dimension	600 x 700 x 363mm, 1500 x 700 x 363mm (pedestal mount)
	Installation method	Wall-mount, Pedestal-mount(optional)
	Cable routing	Bottom inlet, bottom outlet wiring
	Weight	95kgs, 120kgs (pedestal mount)
	Cable length	4m
	Cable outlets	2, single charging
Electrical specifications	Input voltage	400Vac +/-10%, 3-phase
	Input frequency	50Hz/60Hz
	Rated power	40kW
	Output voltage	150 – 750V DC, constant output @ above 300V
	Output current	0 - 66A / 0 - 132A
	Efficiency	≥ 94%
	Power factor	≥ 0.99
Function design	User interface	RFID, 7” touch screen, Emergency button
	Charging standards	IEC 61851, CHAdeMO
	Communication	CAN, PLC, OCPP 1.6 JSON
Environment condition	Application place	Indoor/Outdoor
	Working temperature	-20 ° C ~ +70° C
	Working humidity	5% ~ 95% without condensation
	Altitude	<2000m
	Protection grade	IP54
	Cooling	Forced-air
	MTBF	100,000 hours
	Safety standards	IEC 61851-1, IEC 61851-22, IEC 61851-23, IEC 61851-24, DIN 70121, IEC 15118-3
	Security design	Over/under voltage protection, overload protection, current leakage protection, grounding protection, over temp protection, lightening surge protection

Product Details Show

Product Tags:

IP54 ark 132A Wall Box EV Charger

IP54 ark Three Phase Wall Box EV Charger

IP54 ark OCPP electric car wall charger

Fast OCPP 1.6J Three Phase 132 Amp Wall Box EV Charger
